Wago 221-412 Transparent 2-Pole Compact Lever Operated Connector with CAGE CLAMP – Pack of 100
The Wago 221-412 is a compact, user-friendly solution for connecting solid and stranded cables up to 4 mm². Its transparent housing, lever operation, and advanced CAGE CLAMP technology ensure quick, reliable, and secure wire connections for various applications.
- Compact Design: Requires up to 40% less space than the original WAGO 222, allowing for more efficient installations.
- Transparent Housing: Ensures wires are correctly inserted and stripped to the proper length.
- Versatile Compatibility: Accommodates solid, stranded, and fine-stranded wires from 0.14 to 4 mm².
- High Ratings: Operates up to 32A/450V with a maximum continuous temperature of 105°C, suitable for small and large loads.
- Ease of Use: Reduced operating force makes termination quick and easy.
- Testing Made Simple: Equipped with two test ports compatible with all standard test probes.
Technical Specifications
- Connection Type: Lever-operated with CAGE CLAMP® technology
- Number of Poles: 2
- Voltage Rating: 450V
- Current Rating: 32A
-
Temperature:
- Maximum Continuous Operating Temperature: 105°C
- Ambient Temperature: Up to 85°C
-
Wire Compatibility:
- Stranded: 0.14 – 4 mm²
- Solid/Fine-Stranded: 0.2 – 4 mm²
| Ean Code | 4050821808435 |
| Product | Connector |
| Type | Lever |
| Colour | Transparent |
| Length | 18.6 mm |
| Unit Weight | 0.001 kg |
| Width | 13.1 mm |
| Current Rating | 32 A |
| Qualifier | Compact |
| Pack Quantity | 100 |
| Voltage (max) | 450 V |
| Terminal Material | Copper |
| Cable Size Range | 4Sq mm mm2 |
| Current Rating (max) | 32 A |
| Insulation Colour | Clear |
